| Place of Origin: | Zhejiang, China |
| Brand Name: | SUNRISE |
| Certification: | CE Certificate |
| Model Number: | SR-350B |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $11,500.00 - $12,000.00/sets |
| Packaging Details: | wooden case |
| Supply Ability: | 30 Set/Sets per Month |
| Condition: | New | Type: | Die-cutting Machine |
|---|---|---|---|
| Computerized: | Yes | Voltage: | 220V/380V |
| Power: | 4kw | Dimension(L*W*H): | 2900*1300*1450mm |
| Weight: | 1700kg | Warranty: | One Year |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Product Name: | Screen Safegurd Die Cutting Machine |
| Model: | SR-350B | Speed: | 180 Press/min |
| Usage: | Film, Foam,laser,Aluminum Foil | Name: | Platen Die Cutting Machine |
| Port: | Ningbo/Shanghai | ||
| High Light: | Servo Transmission die Cutting Machine,3kw die Cutting Machine,3kw Automatic Die Cutter |
||
Automatic Die Cutting Machine Servo Transmission 3kw automatic die cutter
product description:
This die cuntting machine is developed on the basis of A model machine,this machine frame is casted on the whole, machine has large power to run and press, so make machine run stably and durably. It contains an oil gear box which reduces abrasion to the machine during the operation, to make machine long life.
Specification
|
model |
SR-350B |
SR-450B |
|
Max. Feeding width |
350mm |
450mm |
|
Cutting area |
340*340mm |
440*440mm |
|
Cutting speed |
30-180 press/min |
30-160 press/min |
|
Position accuracy |
±0.10mm |
±0.10mm |
|
Power of main motor |
2.2kw |
3kw |
|
Size(L*W*H) |
2900*1300*1450 |
3000*1500*1450mm |
|
Unwinding/rewinding diameter |
550mm |
550mm |
|
Voltage |
220/380v |
380v |
|
Total power |
4kw |
5.5kw |
|
weight |
1700kg |
2500kg |
