350Z Medium Speed Die Cutting Machine Quotation

1
MOQ
350Z Medium Speed Die Cutting Machine Quotation
Features Gallery Product Description Request A Quote
Features
Specifications
Max. Feeding Width: 350mm
Cutting Area: 330*330mm
Die Cutting Speed: 300 Times/min
Position Accuracy: ±0.10mm
Power Of Main Motor: 3 Kw
Size(L*W*H): 2900*1260*1750
Unwinding/rewinding Diameter: 650mm
Voltage: 380v,3phase
Total Power: 6kw
Weight: 1900kg
Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: SUNRISE
Certification: CE
Model Number: SR-350Z
Payment & Shipping Terms
Packaging Details: exported wooden case
Delivery Time: 40 working days
Payment Terms: T/T
Supply Ability: 30 Set/Sets per Month
Product Description

350Z Medium Speed Die Cutting Machine Quotation

Extended functions: laminating-hot stamping-hole punching

Standard functions: unwinding-die cutting-waste discharging-cutting into pieces-rewinding

The paper adhesive label, nylon membrane trademark and the radium anti-fake trademark.this machine is matching with different printing machine and slitting machine, such as roll paper printing machine,flexo printing machine,screen printing machine,gravure printing machine.

This machine is widely used in electronic line, adhesive product line and so on.





Features:

This machine is insistent of platen pressing structure, servo system control the material feeding and forwarding, the photoelectric eyes track the material colors, unwinding-die cutting-waste discharging-sheet cutting-rewinding all are completed in one turn, all are control by PLC control system.

350Z Medium Speed Die Cutting Machine Quotation 0350Z Medium Speed Die Cutting Machine Quotation 1



Technical parameters:

Model SR-350Z SR-450Z
Max. Feeding width 350mm 450mm
Cutting area 330*330mm 430*430mm
Die Cutting speed 300 times/min 300 times/min
Position accuracy ±0.10mm ±0.10mm
Power of main motor 3 kw 4 kw
Size(L*W*H) 2900*1260*1750 3170*1700*1750
Unwinding/rewinding diameter 650mm 650mm
Voltage 380v,3phase 380v,3phase
Total power 6kw 10kw
weight 1900kg 2500kg
