| Place of Origin: | Zhejiang, China |
| Brand Name: | SUNRISE |
| Model Number: | SR-350G |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $13,000.00/sets >=1 sets |
| Packaging Details: | exported wooden case |
| Supply Ability: | 30 Set/Sets per Month |
| Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Advertising Company | Showroom Location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, India, Mexico, Russia, South Korea, Japan, Malaysia, Australia |
|---|---|---|---|
| Condition: | New | Product Type: | Paper Plate Machine |
| Processing Type: | Cutting Machine | Voltage: | 380V |
| Power: | 11kw | Dimension(L*W*H): | 3300*1400*1500mm |
| Weight: | 2800 Kg | Warranty: | 1.5 Years |
| Production Capacity: | 80m/min | Core Components: | PLC, Pressure Vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox |
| Model: | SR-350G | Max. Feeding Width: | 350mm |
| Max. Speed: | 24000time/h | Max.Length Of Meter: | 80m/min |
| Position Accuracy: | ±0.1mm | No.1 Cutting Area: | 350mmx350mm |
| Max. Unwinder Dia: | 800mm | Max.Rewinder Dia: | 800mm |
| Port: | Ningbo/Shanghai | ||
| Highlight: | Label Die Cutting Machine,380v Die Cutting Machine,Label Die Cutting Machine 380v |
||
1.Adopt PLC system, motion controller
2.24000 times/h , ensure run fast,high accuracy working stable.
3. Use wood die cutter,cheap and durable.
4. Use servo motor for main motor and material pulling,to keep accuracy.
5. Rewind and unwind is separate, it is suitable for film and label die cutting
6. With high speed sheet cutting ,sheet cutting by rotary, controlled by servo motor.
|
Model
|
SR-350G |
|
Brand Name
|
SUNRISE |
|
Voltage
|
380V
|
|
Power
|
11kw
|
|
Dimension(L*W*H)
|
3300*1400*1500mm
|
|
Weight
|
2800kg
|
|
Max. Feeding Width
|
350mm
|
|
Max. Speed
|
24000time/h
|
|
Max.Length of Meter
|
80m/min
|
|
Position Accuracy
|
±0.1mm
|
|
No.1 Cutting Area
|
350mmx350mm
|
|
Max. Unwinder Dia
|
800mm
|
|
Max.Rewinder Dia
|
800mm
|
